High Purity Gas Filling Hose

It is suitable for the connection of standard gas filling, laboratory and valve switching panel. It adopts double structure design, the inner tube is metal bellows, the outer tube is stainless steel woven net, which has the characteristics of high cleanliness and no adsorption residual. The whole tube body is equipped with stainless steel spring, and the two ends are equipped with stainless steel sheath, this product is 100% pressure test and degreasing treatment!

》Send Mail《
Categories: ,

Description

Technical Parameters

Material:SS316L、SS304
Applicable temperature:-40°C~180°C
Pressure:300bra
cleanliness class: class BA
Performance Testing: Air tightness test，Hydrostatic strength test
Length: Customized according to customer needs
hose coupler type: Customize different type according to customer needs

Material Selection

hose coupler:SS316L、SS304/Brass( HPb59-1)
Tube Insert:SS316L、SS304
woven net、spring: SS304
protective sleeve:SS304
Anti-swing rope: Steel wire covered in glue
